**LT3060EDC-5#TRMPBF: A 20V, 500mA Low Noise, Low Dropout Linear Regulator with Programmable Current Limit**

In the realm of power management, achieving a clean, stable, and protected voltage supply is paramount for sensitive analog and digital circuits. The **LT3060EDC-5#TRMPBF** from Analog Devices represents a highly integrated solution, excelling as a **versatile and robust low-dropout (LDO) linear regulator**. This component is engineered to deliver exceptional performance where low noise, high precision, and system protection are critical.

This regulator is capable of supporting a wide input voltage range up to **20V**, making it suitable for a variety of applications, including industrial systems, automotive power supplies, and battery-powered equipment. Its ability to provide a fixed **5V output at 500mA** ensures it can power a broad spectrum of loads, from microcontrollers and sensors to communication modules.

A standout feature of the LT3060EDC is its remarkably **low dropout voltage**. Even at full load current, the dropout voltage is typically a mere 300mV, maximizing efficiency and extending battery life in portable applications. Furthermore, it boasts **ultra-low output noise performance**, typically as low as 30μVRMS across a 10Hz to 100kHz bandwidth. This is achieved without the need for a separate noise-bypass capacitor, though one is provided for even further noise reduction, making it ideal for powering noise-sensitive RF, precision analog, and data acquisition systems.

Beyond its core regulation capabilities, the LT3060EDC incorporates advanced protection features. Its **programmable current limit** is set via a single external resistor, allowing designers to tailor the fault current threshold to their specific system requirements. This provides robust protection for both the regulator and the downstream load during fault conditions. Additionally, the device includes internal protection against over-temperature conditions and reverse current flow.

Housed in a compact 8-lein 3mm x 3mm DFN package, the **LT3060EDC-5#TRMPBF** offers a high-performance power solution in a minimal footprint. Its combination of high voltage tolerance, low noise, low dropout, and programmable current limit establishes it as a superior choice for designing reliable and efficient electronic systems.

**ICGOOODFIND**: The LT3060EDC-5#TRMPBF is a premier LDO regulator that masterfully combines high input voltage capability, ultra-low noise, and excellent load regulation with critical programmable protection features, making it an indispensable component for advanced power management designs.

**Keywords**: Low Dropout (LDO) Regulator, Low Noise, Programmable Current Limit, 500mA, 20V Input.
